10 Inches 250mm Sand Dredger Machine Customized

Brand Name : yongsheng

Model Number : ys-10inch

Place of Origin : china

MOQ : 1

Price : 70000usd/piece

Payment Terms : T/T,L/C

Supply Ability : 100piece/Year

Delivery Time : 30 work days

Packaging Details : Container

Customized : customized

Condition : new

Warranty : 1 year

Water Flow : 900m3/h

Solid Capacity : 150-180 Cbm/H

Max.Dredging Depth 45° : 10m

Discharge Distance : 800m

size : 17M*5.0M*1.2M

Main Engine : 294kw

consumption : 60L/H

Application : sand suction

Work site : river lake sea canal

Auxiliary engine power : 88kw

Core Components : Engine, Pump

Contact Now

Sand Dredger Machine With Cheap Price

Our jet suction sand dredger is equipped with high pressure pump. It washes sand up , then

the sand pump conveys the sand to the destination through the pipe.
Consists of a dredge body, high-efficiency wear-resistant marine sand pump, high-pressure water

pump, famous brand diesel engine, and discharge system. Our New Sand Mining Machine features

an integrated design, high efficiency, good wear resistance, flexible operation, and energy saving

in the delivery of solid particles. Our New Sand Mining Machine is the most economical New Sand

Mining Machine for loose fine sand in the water bottom. We can customize various small and medium

jet suction dredgers for your demands.

10 Inches 250mm Sand Dredger Machine Customized

Product Paramenters:
Model
Soild
capacity
Water flow
Dredging depth
Discharge distance
Main engine
Auxiliary engine
Total consumption
size(m)
6inch
40-50
m3/h
250
m3/h
6M
500M
120
KW
18L/H
10*3.8*1.6
8inch
80-100
m3/h
500
m3/h
8M
500M
176
KW
60KW
40L/H
14*4.5*1.2
10inch
150-180
m3/h
900
m3/h
10M
800M
294
KW
88KW
60L/H
17*5*1.2
12inch
200-250
m3/h
1400
m3/h
10M
1000M
456
KW
110KW
80L/H
20*6*1.5
14inch
300-400
m3/h
2000
m3/h
12M
1500M
735
KW
120KW
120L/H
24*6.6*1.6
16inch
400-500
m3/h
2600
m3/h
14M
1500M
882
KW
258KW
150L/H
24*7.2*1.8
18inch
500-600
m3/h
3000
m3/h
14M
1500M
1103
KW
456KW
220L/H
24*7.6*2.0
20inch
600-700
m3/h
3800
m3/h
14M
1500M
1250
KW
456KW
240L/H
26*7.6*2.0
Note: Because this equipment is a customized product, the maximum conveying distance of one pump is 1000-2000m. If long-distance conveying is required, a separate relay pump group is added.
The above output is calculated based on the conventional flow rate 15-20% concentration. If the long-distance conveying concentration will be reduced, it can be calculated based on about 15% of the flow rate.

10 Inches 250mm Sand Dredger Machine Customized

10 Inches 250mm Sand Dredger Machine Customized

10 Inches 250mm Sand Dredger Machine Customized

Advantage:
1. High efficiency, large output, and long discharge distance.
2. Very simple and fast assembly and disassembly, simple operation, easy to control.
3. Good economic performance.
4. Dredge platform consists of multiple pontoons connected by a proven coupling system.
5. Highly efficient fuel consumption and minimum overall operational costs.
6. Economize human resources. One-man operation in a low-noise operating cabin.
7. Controls box and instruments are mounted on an ergonomic dashboard.
8. We can according to the customer's request make a jet sand suction dredger
